Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display

Brand Name : Bitvisus

Model Number : BIT-VP-U1-MD416

Certification : CE、FCC、GB

Place of Origin : Guangdong China

MOQ : 1

Price : 758

Payment Terms : T/T

Supply Ability : 1000

Delivery Time : 5-8 work days

Packaging Details : 3KG, 54.5cm*46.5cm*12cm

Product name : BIT-VP-U1-MD416

Product type : 4x4 4k60 LCD LED Video Processor

Resolution : 3840x2160@60Hz

Feature : Seamless switching, Roaming, etc.

Function : Splicing, roaming,seamless, switching.

Input : 4 HDMI2.0

Output : 16 HDMI1.4

Input Interface : 600MHz

Output Interface : 148.5MHz

Warranty : 3 Years

Contact Now

Bitvisus 4K60 Seamless Switching Display Wall Controller
4 Input 16 Output Video Wall Controller supporting 3x5 and 4x4 video wall configurations with advanced video processing capabilities.
Product Overview
Professional 4K60 seamless switching and roaming video wall processor designed for high-performance display applications.
  • Supports 4-way 4K60 input with 2 HDMI or DP bi-optional inputs and 16-way 1920×1080P60 output for crystal-clear image quality
  • Enables 16-screen horizontal and vertical splicing using advanced image processing technology
  • Supports 4-screen simultaneous display with windows of any position, size, and overlay roaming capabilities
  • Features seamless switching of input signals without screen blackout
  • Advanced window management with transparency adjustment, layer switching, and hiding/masking functions
  • Supports screen mirroring and whole screen freezing for presentation flexibility
  • Includes 10 preset configurations for quick saving and recalling
  • Local display back support when screen count is ≤12
  • HDMI audio output with 4-way 3.5mm audio separation
  • Multiple control options: remote control, pushbutton, RS232, host computer, and keyboard shortcuts
  • Enables simultaneous control of 4 computers through single keyboard and mouse setup
Contact us to consult about the products required by your project!
Product Specifications
Product Name BIT-VP-U1-MD416
Input Interface Type HDMI2.0×4, DP1.2×2
Input Interface Maximum Video Pixel Frequency 600MHz
Maximum Resolution 3840×2160@60Hz
Color Format RGB444, YUV444, YUV422, YUV420
Output Interface Type HDMI1.4×16
Output Interface Maximum Video Pixel Frequency 148.5MHz
Output Resolution 1920×1080@60Hz
Control Method Remote control, Pushbutton, RS232, Windows host computer
Audio HDMI Audio Follow-On, 3.5MM Audio Separation
Power Supply 220V
Power Consumption 50W
Storage/Working Temperature -10 to 50ºC / 0 to 50ºC
Product Size L×W×H: 482.6 mm × 250 mm × 59 mm
Package Size L×W×H: 545 mm × 465 mm × 120 mm
Product Weight 2KG
Packing Weight 3KG
Accessories List 1 × 220V Power cable, 1 × HDMI cable or DP cable, 1 × blue network cable, 1 × IR infrared head, 1 × remote control, 1 × USB A-B cable
After-sales Warranty 3 years warranty
Features at a Glance
Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display
Company Profile
Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display Bitvisus 4K60 Video Wall Controller with 16 HDMI Outputs and Seamless Switching for Multi-Screen Display
Frequently Asked Questions
Why Choose Bitvisus?
  • We maintain our own warehouse ensuring order shipment within 48 hours after payment (excluding weekends and holidays)
  • OEM/ODM services available for customized solutions
  • Extensive product portfolio including Video Wall Controller, Multiscreen Expander, Multiviewer, Embedded Projector Fusion demonstrating strong R&D experience and quality assurance
Shipment & Payment
  • Payment Methods: T/T, Visa, PayPal, Western Union, L/C
  • Shipping Options: DHL, UPS, EMS, FedEx, Air freight, Sea freight
How to Order?
  • Contact us via email, TM, WhatsApp, or Skype with your order requirements
  • We will provide a proforma invoice based on your specifications
  • After payment confirmation, we will expedite delivery of your goods
